Principle and Application of VSR


Principle and Application of VSR

VSR process development
Method using a vibrating metal components to eliminate the residual stress techniques, in 1900 obtained a patent in the United States. However, long-time use of heat, coupled with the vibration to eliminate stress at the time the mechanism is not very clear, and high-speed motor has not yet caused the heavy equipment, adjust the inconvenience, so the technology has not been developed and applied.
Until the 1960s the energy crisis, the United States, Britain, Japan, Germany and other countries only began to study the mechanism and application of VSR process. Since the 1970s, especially to the emergence of adjustable speed motor, vibration to eliminate stress to promote the device (VSR system) development: in 1973 the British made portable VSR system that VCM80, Martin Engineering Company and later the United States has developed a more advanced equipment LT-100R-based VSR system. France and the Soviet Union were also produced PSV-and NB-based VSR system. The excitation of these more advanced devices, vibration to eliminate stress to promote the development and application of technology.
According to statistics, currently the world's VSR system is being used about one million units. U.S. VSR process using more than 700 companies, the Soviet Union and Eastern European countries are also widely used, have achieved significant economic benefits. Many countries have set the VSR must be used for some mechanical components of the standard process. Almost no company in the UK do not use the technology.
VSR equipment applications
Vibration treatment abroad relatively wide range of applications, the component types to be handled more. For example:
1. British company producing large precision machine tools, the column bed with required accuracy 0.01mm/2m. Thermal aging in the past to maintain its accuracy is poor, then use VSR to meet the accuracy requirements, so now has the product VSR as the standard process.
2. UK production of aluminum alloy casting precision pump, the size of 275 × 300 × 150mm, but also with the VSR to ensure its accuracy.
3. U.S. PX engineering company, with the VSR to eliminate 8 tons of welded structure gears of internal stress, to reduce weld cracking.
4. U.S. Pont Land electronics specialist with the technology for 4 tons of forging blank. The company provides treatment forging three times the vibration:
(1) blank (2) after roughing (3) after finishing. Three treatment after forging to ensure stability.
5. Washington, United States Steel Corporation, the company produced 47 tons of heavy shears seat vibration treatment. Shears seat is 152mm to 203mm thick steel plate welded into, ribs 38mm to 76mm thick so large and heavy components only 40 minutes of vibration treatment on the past instead of the thermal aging.
6. Northwest Industries of America 2800 tons of heavy marine tower and 1280 tons of heavy drilling platform also used over vibration aging treatment.
7. British land use VSR wellhead platform, wellhead platform is 200mm diameter steel pipe welded into 6m × 6m × 2m tube frame.
8. British jet engine flame tube lining, due to the occurrence of post-weld heat expansion cracks, scrap rate of 30% or more, then the use of VSR process, scrap rate is almost zero.
9. UK production of all special machine bed is replaced with the VSR heat aging. More than 30 dozen Forging Machine Tool Plant and Equipment Factory is the VSR as a standard production process.
United States, Britain and other countries also in other industrial sectors using VSR Dali, such as Paper Machinery Factory, ships bearing plants, laser welding machine factory, gearbox factory, textile machinery, steel rolling plant, Printing Machinery, pump factory , oil equipment factory, power plant, boiler plant and so the application of VSR to eliminate the stress components.
Since 1975, the technology in China has been rapid development and promotion of the machine castings made great breakthrough.
Over the years, on the VSR fatigue life of welded components is the impact of domestic and foreign experts of great interest and debate focused. Some of our units to do a lot of research, concluded that the VSR on the mechanical properties of metallic materials have a greater impact, reasonable VSR process can improve the fatigue life of welded components. These conclusions for the VSR in the application of welded components on a theoretical foundation.
VSR process in the country after twenty years of research and application, many companies are based in some important parts of the application of the VSR technology.
1. Harbin Electrical Machinery Plant manufacturing power plant equipment in a large generator base, cover, ring, turbine guide vanes.
